2-post lift KPX40AV

4.0 t, electromechanical, AV arms, symmetrical posts, 3-stage long arms, 3-stage short arms, TEq-Link

MPN: RAV.KPX40.198204
GTIN (EAN): 5063084198204
Category:
Tags: ,

Share on:

Description

Legend Series – From History to the Future

  • Up-to-date design: modern outline that brings modernity and usability to the workshop
  • Innovative DNA: long-standing high-quality components and tested for 20000 cycles
  • Future-proof: lifts designed for the TEq-Link workshop connectivity system

Emerging from the bestselling 2-post lifts, the Legend Series consolidates the engineering knowledge of Ravaglioli and shapes it into an innovative package. Looking towards the future while always honouring the past, Ravaglioli has set an important goal for itself – let the performance meet the design.

  • The geometry of the arms is designed to lift every type of car from classic city cars to vans.
  • The innovative AV (“All Vehicles”) arms extend 20% further than conventional arms, allowing them to reach the lifting points of a wide range of vehicles.
  • High-performance motors.
  • Automatic arm lock and automatic ground release: conical geometry with self-locking effect.
  • Permanent and automatic lubrication of the nuts to ensure effective operation during upward and downward movement.
  • High-strength rolled steel screw for maximum durability.
  • Arms made of special steel, with first stage height just 70 mm and second stage height 85 mm.
  • Equipped with an acoustic anti toe trap system – Free from mechanical foot guards.
  • Premium quality of components:
    • Aluminium pulley with cooling function.
    • Long lasting bearings.
    • 50% longer, bronze load nut.
    • Motors with reinforced and cooling casing.
    • Solid automatic arm locking.

Media

Accessories

Tech Data

Features2-post lift KPX40AV2-post lift KPX40AV
Number of columns2
Mode of driveelectromechanical
Controlelectric
Type of installationfloor mounted
Rated load capacity4000kg
Max. lifting height2011mm
Lifting time58s
Min. plate height97mm
Max. plate heigh127mm
Clear span between2700 – 2800mm
Clear span between (out)3194 – 3094mm
Column height2863mm
Drive-through width2504mm
Required ceiling height4100mm
Surface coatingPowder coated
Arm layoutasymmetrical
Telescopic front arms3-fold
Telescopic rear arms3-fold
Min. front arm length470mm
Max. front arm length1039mm
Min. rear arm length700mm
Max. rear arm length1480mm
Driving power2 x 3,5kW
Power supply400 V | 50 Hz
Width3428 – 3528mm
Height4000mm
