Fixed length of platforms for easy use. The best solution for a rational workshop.
3.5 t, electrohydraulic, inground | 3 x 230/400 V / 60 Hz
3.0 t, low-profile (95 mm), electrohydraulic, above ground
Suitable for RAV.640N1.193391, RAV.650N1.193742, RAV.650N2.193858, RAV.650N2.193520, RAV.650N2.193667, RAV.650N6.193964, RAV.650N5.193902, RAV.660N2.193360, RAV.650N5.193018, RAV.650N6.193025, RAV.640N5.193049, RAV.640N4.192998, RAV.640N3.192981, RAV.80552.196736, RAV.80555.196811, RAV.80652.196910, RAV.509IF.196071, RAV.509IF.196354,…
Mounting the operating unit in a special position – in drive-up direction “right” from the platform, at a distance of…
| Features | Double scissor lift RAV509IF | Double scissor lift RAV509IF | Double scissor lift RAV518T |
|---|---|---|---|
| Scissor lift design | Double scissors | Double scissors | Double scissors |
| Mode of drive | electrohydraulic | electrohydraulic | electrohydraulic |
| Type of installation | surface mounted | surface mounted | floor mounted |
| Rated load capacity | 3500kg | 3500kg | 3000kg |
| Max. lifting height | 1825mm | 1825mm | 1900mm |
| Max. lifing height at floor level | 1825mm | 1825mm | — |
| Lifting time | 41s | 41s | — |
| Lowering time | 41s | 41s | — |
| Play detector | not possible | not possible | not possible |
| Drive-on-height | 255mm | 255mm | 95mm |
| Wheel alignment | not possible | not possible | not possible |
| Length of platforms | 1580mm | 1580mm | 1940mm |
| Width of platforms | 510mm | 510mm | 610mm |
| Wheel free lift | not possible | not possible | not possible |
| Driving power | 2,6kW | 2,6kW | 2,6kW |
| Power supply | 230/400 V | 50 Hz | 230/400 V | 60 Hz | 230/400 V | 50 Hz |
| Length | 1610mm | 1610mm | 1940mm |
| Width | 1920mm | 1920mm | 2020mm |
| Weight | 815kg | 815kg | 715kg |
