Description
Truck tyre changer for both road-side and workshop service, suitable for closed vans and/or small workshops.
- Hydraulic chucking table
- Suitable also for agricultural tyres
Media
Similar Products
-
Tyre changers
Tyre changer G96N
MPN: RAV.G96NX.206282Universal, Quick-Fit system mounting tool, max. speed 8 rpm, hydraulic operating unit, truck, rim diameter 11 – 27″, max. rim…
-
Tyre changers
Tyre changer GRS926.MOVI
MPN: RAV.GR926.206312Mobile tyre changer for installation in vans, max. speed 8 rpm, cable hydraulic console unit, truck, rim diameter 11 -…
-
Tyre changers
Tyre changer GTB16EVO
MPN: RAV.GTB16.206305Mounting head and mounting lever, for commercial vehicle tubeless tyres, synchronized double bead breaking, max. speed 8 rpm, hydraulic operating…
Accessories
-
Accessories tyre changers
Bead-locking clamp for alloy rims
MPN: G90A6Protection for alloy rims
-
Accessories tyre changers
Mounting lever
MPN: G108A3Short, patented
-
Accessories tyre changers
Rings lever for trucks
MPN: G108A13 -
Accessories tyre changers
Brush wood, angled
MPN: G108A16For wheel assembly machines
-
Accessories tyre changers
Grease paste for tyre mount/dismount | 3.5 kg
MPN: G800A37 -
Accessories tyre changers
Clamp protections for alloy rims | 1 set / 4 pieces
MPN: G108A2 -
Accessories tyre changers
Bead breaker disc for snap rings
MPN: G108A22 -
Accessories tyre changers
Pneumatic bead pushing device for agricultural tyres
MPN: G108A34
Tech Data
| Features |  Tyre changer GRS926 | Tyre changer G96N | Tyre changer GRS926.MOVI | Tyre changer GTB16EVO |
|---|---|---|---|---|
| Mounting head design | Automatic | Automatic | Automatic | With tire lever |
| Mounting arm design | Moveable | Swiveling | Moveable | Moveable |
| Mounting column design | Rigid | Rigid | Rigid | Rigid |
| TeqLink | Not possible | Not possible | Not possible | Not possible |
| Workshop-Net | Not possible | Not possible | Not possible | Not possible |
| Clamping device design | central | central | central | central |
| Min. clamping capacity | 11″ | 11″ | 11″ | 11″ |
| Max. clamping capacity | 27″ | 27″ | 27″ | 27″ |
| Max. rim width | 37″ | 36,4″ | 37″ | 21″ |
| Min. rim diameter | 11″ | 11″ | 11″ | 11″ |
| Max. rim diameter | 27″ | 27″ | 27″ | 27″ |
| Tire type truck | Standard | All types | Standard | Standard |
| Max. wheel width | 950mm | 925mm | 950mm | 540mm |
| Max. wheel diameter | 1300mm | 1640mm | 1300mm | 1320mm |
| Max. wheel weight | 1200kg | 1500kg | 1200kg | 1200kg |
| Automatic bead-breaking movement | Yes | Yes | Yes | Yes |
| Bead breaker force | 16kN | 18kN | 16kN | 12,5kN |
| Number of mounting speeds | 1 | 1 | 1 | 1 |
| Rotation speed | 8rpm | 8rpm | 8rpm | 8rpm |
| Max. torque | 1700Nm | 3000Nm | 2200Nm | 2600Nm |
| Chuck motor rating | 1,1kW | 0,75kW | 1,5kW | 1,5kW |
| Driving power | 2kW | 2,2kW | 2,2kW | 2kW |
| Electrical connection | 400 V | 50 Hz | 230/400 V | 50 Hz | 400 V | 50 Hz | 400 V | 50 Hz |
| Phases | 3 | 3 | 3 | 3 |
| Width | 1095mm | 1620mm | 890mm | 2810mm |
| Depth | 1954mm | 1860mm | 2235mm | 1405mm |
| Height | 1691mm | 1360mm | 1715mm | 2130mm |
| Country of Origin, customs | IT | IT | IT | IT |
