2-Cylinder Inground Lift RAV1125M

3.5 t, with flat beam support, extendable and transversely movable in the direction of travel

MPN: RAV1125M
GTIN (EAN): 4057612815450
Category:
Tags:

Share on:

Description

  • Perfect synchronization between cylinders regardless of load distribution.
  • Equipped with safety valve to prevent overloading and in case of hydraulic pipe fracture.
  • Self-controlled lowering speed.
  • All mechanical, hydraulic and electrical components manufactured in compliance with the respective European Safety Standard.
  • Maintenance free cylinders: Each column features a maintenance-free lifting cylinder
  • Double joint: Cross bar with double joint to eliminate vibrations
  • Safe – Mechanical lock: Mechanical safety latch with automatic engagement, ensuring maximum safety when lift is in standing position.
  • Hard chrome columns: Hard chrome columns grant long life
  • Maintenance free guides: Columns guides in oil bath, maintenance free
  • Waterproof inground frame: steel frame and plastic cover
  • Lift with adjustable platforms: both in length and in width
  • Min. height: 95 mm

Media

Similar Products

Tech Data

Features2-Cylinder Inground Lift RAV1125M2-Cylinder Inground Lift RAV1125M2-Cylinder Inground Lift RAV11252-Cylinder Inground Lift RAV11252-Cylinder Inground Lift RAV1110NK2-Cylinder Inground Lift RAV1110NK2-Cylinder Inground Lift RAV1110LR2-Cylinder Inground Lift RAV1110LR2-Cylinder Inground Lift RAV1155LIKTA2-Cylinder Inground Lift RAV1155LIKTA
Number of rams22222
Inground lift designFlat beamFlat beamSwivel armSwivel armSwivel arm
Type of installationSurface mountedSurface mountedSurface mountedSurface mountedSurface mounted
Capacity3500kg3500kg3500kg3500kg5500kg
Max. lifting height1990mm1990mm2063mm2019mm2019mm
Plunger diameter120mm120mm120mm180mm210mm
Расстояние между стойками1340мм
Wheel alignmentNot possibleNot possibleNot possibleNot possibleNot possible
Длина1950мм
Ширина1800мм
Длина фундамента1670мм
Ширина фундамента395мм
