The GTB16EVO is a one-of-a-kind. It is equipped with four rollers with a unique form, positioned on the two sides of the wheel in diametrically opposite positions. With the system, the dismounting of the tyre with bead breakers is very simple and natural: while the anterior bead breakers keep the bead in the drop centre, the posterior ones continue their course until the dismounting is complete.
- 30 seconds you need to dismount and mount a common truck tyre
- The chucking unit, designed to clamp all kind of wheels, and can move not only clockwise and counterclockwise, but also up and down
- Thanks to the “STAND-BY” function, we totally eliminate the noise when the machine is not working
- The bead breakers are made of plastic material to prevent damage to the rim
- Hydraulic chucking table — Suitable also for agricultural tyres (+G108A24)
- All movements are hydraulically controlled from a convenient, ergonomically positioned console
- The machine is equipped with a patented lever to ease the mounting/demounting of the tyre
- The bead breakers are supported by two arms separately commanded — Each arm has two rollers, one conical which pushes on the bead and one cylindrical which punches the tyre side wall
- The operating dimensions of the rim clamping unit and of the head-tool carriage allow the tyre changer to operate on a whole range of wheels, including super-single
